Epson EB-L630U WUXGA 3LCD Laser Projector
Robust, Compact WUXGA Laser Projector with 6,200lm and Built-In Wireless
The compact, low running cost EB-L630U laser projector delivers powerful performance for education and business applications. Get bright, vivid images with 6,200 lumens of white & colour brightness*2. This robust projector also offers WUXGA resolution. Featuring breakthrough laser technology, it delivers a laser light source of up to 20,000 hours*1 and offers virtually maintenance-free operation with no lamps. Plus, it features an optical zoom of up to 1.6x. It also supports split screen function of up to 4 screens enabling better information sharing and wide lens shift for greater flexibility. Besides this, it also comes with flexible settings for image enhancement to further sharpen image resolution to your preferences. It is compatible with the Epson Wireless Presentation System** which enables hassle-free connectivity for better productivity.
6200 lumens of color and white brightness*2
20,000-hour*1 laser light source with no lamps
WUXGA resolution
Built-in Wireless
1.6x Optical Zoom
Screen size of up to 500″
What’s in the box:
Power Cable (3m)
Remote Control with 2x AA Battery
User Guide
Cable Cover
Projection Technology:
Projection Technology:RGB liquid crystal shutter projection system (3LCD)
Connectivity:
Network:Wired LAN RJ45 x 1 (100Mbps)
Built-in Wireless: Yes
Optional Wireless: ELPAP11Analog Input:D-Sub 15Pin: 2Digital Input:HDMI: 2 (HDCP 2.3)
HDBaseT: 1 (HDCP 2.3)Audio Input:Stereo Mini Jack: 2Audio Output:Stereo Mini Jack: 1Control I/O:RS-232C: D-Sub 9pin x 1USB Input:USB Type A: 2 (Port 1 for PC Free, Firmware Update, Copy OSD Settings; Port 2: for 5V/2A power supply only, no USB function)Analog Video Output:D-Sub 15Pin: 1Digital Video Output:HDMI: 1 (HDCP 2.3)
HDBaseT: 1 (HDCP 2.3)
Contrast Ratio:
Contrast Ratio:Over 5,000,000:1
Screen Size (Projected Distance):
Zoom : Wide:50″ – 500″ [1.44 – 14.76 m]Zoom : Tele:50” – 500” [2.35 – 23.84 m]
Geometric Correction:
Vertical/Horizontal Keystone:±30º / ±30ºProjection Orientation:360º Free
Operating Temperature:
Single Use:Low Altitude (0 – 2,286m/7,500ft): 0 – 45 °C <32 – 113 °F>
High Altitude (Over 2,286m/7,500ft to 3,048m/10,000ft): 0 – 40 °C <32 – 104 °F>
20% – 80% Humidity, No CondensationMulti-projection Use:Low Altitude (0 – 2,286m/7,500ft): 0 – 40 °C <32 – 104 °F>
High Altitude (Over 2,286m/7,500ft to 3,048m/10,000ft): 0 – 35 °C <32 – 95 °F>
20% – 80% Humidity, No Condensation
Operating Altitude:
Operating Altitude:Over 1,500m/4,921ft with High Altitude Mode: 0 – 3,048m (0 -10,000ft)
Start-Up Period:
Start-Up Period:8 sec (Epson Logo); Warm-up Period: 30 secQuick Start-Up:Less than 5 seconds (Display)
Cool Down Period:
Cool Down Period:Instant Off
Internal Speaker(s):
Sound Output:10W Monaural
Direct Power On/Off:
Direct Power On/Off:Yes
Weight:
Weight:Approx. 8.4kg
Air Filter:
Type:Electrostatic FilterMaintenance Cycle*4:20,000 hours (Normal) / 30,000 hours (Extended)
Fan Noise:
Fan Noise (Normal / Eco):38dB / 27dB
Dimension Excluding Feet:
Dimension Excluding Feet (D x W x H):304 x 440 x 122 mm
Brightness:
White Light Output (Normal / Extended):6,200lm / 4,340lmColour Light Output:6,200lmLight Output (Center):6,500lm*
Wireless Specification (In-built wireless LAN and Screen Mirroring):
Supported Speed for Each mode :Infrastructure:
IEEE 802.11b (2.4GHz): 11 Mbps*3
IEEE 802.11g (2.4GHz): 54 Mbps*3
IEEE 802.11n (2.4GHz): 72.2 Mbps*3
IEEE 802.11a (5GHz): 54 Mbps*3
IEEE 802.11n (5GHz): 150.0 Mbps*3
IEEE 802.11ac (5GHz): 325Mbps*3
Access Point(Wi-Fi Direct):
IEEE 802.11g (2.4GHz): 54 Mbps*3
IEEE 802.11n (2.4GHz): 72.2 Mbps*3
IEEE 802.11a (5GHz): 54 Mbps*3
IEEE 802.11n (5GHz): 150.0 Mbps*3
IEEE 802.11ac (5GHz): 325Mbps*3Supported Mode :Supported Mode: Infrastructure, Access Point(Wi-Fi Direct)Supported Security Type:Infrastructure:
OPEN, WPA2/WPA3-PSK
WPA2/WPA3-EAP
Supported EAP type:
PEAP, PEAP-TLS, EAP-TLS, EAP-Fast)
Access Point(Wi-Fi Direct):
WPA2-PSK(AES)
Wireless Specification (Using Optional ELPAP11):
Supported Speed for Each mode :Access Point(Wi-Fi Direct):
IEEE 802.11g (2.4GHz): 54 Mbps*3
IEEE 802.11n (2.4GHz): 72.2 Mbps*3
IEEE 802.11a (5GHz): 54 Mbps*3
IEEE 802.11n (5GHz): 150.0 Mbps*3
IEEE 802.11ac (5GHz): 325Mbps*3Supported Mode :Access Point (Wi-Fi Direct)Supported Security Type:Access Point (Wi-Fi Direct): WPA2-PSK (AES)
Specifications of Main Parts:
LCD:Size: 0.67″ (C2 Fine)
Resolution: WUXGA
Aspect Ratio: 16:10Lightsource:Type: Laser Diode
Life*1: 20,000 hours (Normal) / 30,000 hours (Extended)Projection Lens:Type: Optical Zoom (Manual) / Focus (Manual)
F-Number: 1.50 – 1.70
Focal Length: 20 – 31.8 mm
Zoom Ratio: 1.0 – 1.60
Throw Ratio: 1.35 – 2.20 (Wide – Tele)
Power Supply Voltage:
Power Supply Voltage:100 – 240 V AC ±10%, 50/60 Hz
Power Consumption (220 – 240V):
Laser Diode ON (Normal / Extended):345 W / 258WStand By:(Normal/Eco): 2.0W / 0.3W
Projectors Facets:
Resolution, Projectors Facets:WUXGAContrast Ratio, Projectors Facets:5,000,000 : 1Inputs & Interfaces, Projectors Facets:RJ-45 & RS-232Brightness Range Lumens, Projectors Facets:4001Features, Projectors Facets:Edge Blending
Screen Mirroring
WifiLaser / Lamp, Projectors Facets:Laser
